FoldXpert Series
FoldXpert Folder Gluer
High-speed intelligent folding & gluing, dual-use.
What is a folder gluer?
A folder gluer takes flat die-cut blanks and folds, applies glue and forms them into finished cartons at high speed. The FoldXpert is a dual-use (carton + corrugated) machine with modular feeder, pre-fold, lock-bottom, folding and transfer sections that can be freely configured for the box style you run.
The FoldXpert Series (850 / 1100 / 1250A) runs at up to 400 m/min with independent servo drives and a six-section modular layout — paper feeding, pre-folding, lock-bottom, folding, transfer and pressing conveyor — so straight-line, crash-lock, 4 & 6-corner and double-wall boxes are all in reach. For wide, two-sheet corrugated work, see the DuoFoldXpert Series.
Key benefits
- Speeds up to 400 m/min with servo accuracy
- Six freely-configurable sections for any box style
- Dual-use: folding carton and corrugated board
- Electronic spray-adhesive system, precise glue placement
- Quick job changeovers for high-mix production
Usage & characteristics
- 01Speeds up to 400 m/min with independent servo drive on each section.
- 02Six freely-configurable sections — feeder, pre-fold, lock-bottom, fold, transfer, pressing conveyor.
- 03Dual-use: folding carton and corrugated board (210–800 gsm; A/B/C/E/F flute).
- 04Wedge belt-wheel transmission for accurate high-speed paper transfer.
- 05Electronic spray-adhesive system with 2–3 cold-glue guns, configurable by model.
- 064 & 6-corner and other box styles easy to add; quick job changeovers.
Applications & industries
Specifications
- Models
- FoldXpert 850 / 1100 / 1250A
- Max speed
- Up to 400 m/min
- Board
- Paperboard 210–800 gsm; A/B/C/E/F corrugated
- Box styles
- Straight-line, lock-bottom, 4 & 6-corner, double-sided, flat
- Drive
- Independent servo motors per section
- Gluing
- Electronic spray adhesive, 2–3 cold-glue guns
- Sections
- Feeder, pre-fold, lock-bottom, fold, transfer, conveyor
Models
- FoldXpert 850 / 1100 / 1250AHigh-speed intelligent folder gluer in three widths.
Models
Models & specifications — FoldXpert Series
Each tab is a distinct model type. Where a type comes in several sizes, they are compared side by side.
FoldXpert 850 / 1100 / 1250A
High-speed intelligent folder gluer in three widths.
| Specification | 850 | 1100 | 1250A |
|---|---|---|---|
| Max blank width | 850 mm | 1100 mm | 1250 mm |
| Max speed | Up to 400 m/min | Up to 400 m/min | Up to 400 m/min |
| Board | 210–800 gsm; A/B/C/E/F flute | 210–800 gsm; A/B/C/E/F flute | 210–800 gsm; A/B/C/E/F flute |
| Box styles | Straight-line, lock-bottom, 4 & 6-corner, flat | Straight-line, lock-bottom, 4 & 6-corner, flat | Straight-line, lock-bottom, 4 & 6-corner, flat |
| Drive | Independent servo per section | Independent servo per section | Independent servo per section |
| Gluing | Electronic spray, 2–3 cold-glue guns | Electronic spray, 2–3 cold-glue guns | Electronic spray, 2–3 cold-glue guns |
FoldXpert 850 / 1100 / 1250A
Available in 3 sizes. Request a tailored quotation, full technical drawing and ROI for the size you need. Installation, operator training and AMC included.
See it in action
FoldXpert Folder Gluer — in operation
Gallery
Return on investment
The numbers that matter
FAQ
Common questions
What is a folder gluer?
A folder gluer folds flat die-cut blanks and applies glue to form finished cartons automatically at high speed.
What box styles can the FoldXpert make?
Straight-line, crash lock-bottom, 4-corner, 6-corner, double-sided and flat boxes — sections are freely configurable.
Is the FoldXpert suitable for corrugated and carton?
Yes. It is a dual-use machine handling paperboard 210–800 gsm and A/B/C/E/F corrugated board.
What is the difference between FoldXpert and DuoFoldXpert?
FoldXpert (850–1250A) is for standard carton and light corrugated work. DuoFoldXpert is a high-speed two-sheets folder gluer for wide formats up to 2600 mm and larger corrugated cartons.
