StitchXpert Series
StitchXpert Box Gluer & Stitcher
High-speed gluing & stitching for finished corrugated boxes.
What is a gluers & stitcher?
After a box blank is printed and slotted, the manufacturer joint is closed by gluing or stitching. StitchXpert covers both: an automatic folder-gluer that folds and glues at speed, and semi-automatic stitchers that nail single, double or reinforced stitches for heavy-duty boxes.
The StitchXpert automatic folder-gluer feeds with bottom-suction belts for smooth high-speed running, gluing the joint with no spill — saving labour and half the glue cost versus manual. The semi-automatic stitchers use HMI touch control with automatic counting and bundling; the double-piece model adds four-servo control to nail single, double and reinforced stitches in one pass.
Key benefits
- Automatic folder-gluer — fast, clean glued joints
- Semi-auto stitchers: single, double & reinforced nailing
- Single-piece stitcher up to 600 nails/min · 2000+ boxes/hr
- Four-servo double-piece stitcher, one-minute size change
- HMI touch control, automatic count & bundling
- Saves labour and ~half the glue cost vs manual
Usage & characteristics
- 01Suits A / B / C / AB corrugated board, three- and five-layer.
- 02Full computer control — simple operation, stable quality, great labour saving.
- 03One machine, three uses: nailing, gluing, and glue-before-nail in one pass.
- 04Auto feeding, line-touching, folding, deviation correction, nailing/gluing, counting and stacking.
- 05Can nail bottomless / covered boxes.
- 06Touchscreen display with fault description; stores up to 1000 order groups.
- 07Order changeover in 3–5 minutes for mass production.
- 08Vacuum-belt feeding for accurate, skew-free paper feed; nailing accuracy ±2 mm.
- 09Box height range 40–500 mm; 45° corner handling.
Applications & industries
Specifications
- Types
- Auto folder-gluer · single- & double-piece stitchers
- Gluer feed width
- 340–2800 mm
- Stitch speed
- up to 600 nails/min
- Stitch range
- 20–120 mm
- Output
- 2000+ boxes/hour (single-piece)
Models
- Automatic Folder-GluerBottom-suction feed, automatic gluing, counting and stacking.
- Semi-Auto Stitcher — Single-pieceHigh-speed single-piece stitcher with HMI control.
- Semi-Auto Stitcher — Double-pieceFour-servo double-piece stitcher for single, double & irregular boxes.
Models
Models & specifications — StitchXpert Series
Each tab is a distinct model type. Where a type comes in several sizes, they are compared side by side.
Automatic Folder-Gluer
Bottom-suction feed, automatic gluing, counting and stacking.
Key difference
Closes the box joint with glue automatically at high speed — bottom-suction belt feed, no glue spill, auto count and stack-out. Saves labour and about half the glue cost versus manual gluing.
| Specification | |
|---|---|
| Feeding width | 340–2800 mm |
| Feeding length | 250–1300 mm |
| Speed | 40–60 pcs/min |
| Power | 3 kW |
| Weight | 2000 kg |
| Machine size | 4300 × 2000 × 1700 mm |
Automatic Folder-Gluer
Request a tailored quotation, full technical drawing and ROI. Installation, operator training and AMC included.
See it in action
StitchXpert Box Gluer & Stitcher — in operation
Gallery
Return on investment
The numbers that matter
FAQ
Common questions
What is the difference between gluing and stitching a box?
Gluing bonds the manufacturer joint with adhesive (clean, fast, lower cost); stitching nails the joint with wire stitches for extra strength on heavy-duty boxes. StitchXpert offers both.
How fast is the StitchXpert single-piece stitcher?
Up to 600 nails per minute and 2000+ boxes per hour, with single, double or reinforced stitches and one-minute size changeover.
Which model suits irregular boxes?
The four-servo double-piece stitcher handles single, double and irregular boxes with electronic stitch-pitch control.
Request a quote
Interested in the StitchXpert Box Gluer & Stitcher?
Tell us your board type, volumes and box styles. We reply within one business day with specs, pricing and a tailored ROI — plus installation and service terms.
