CorrXpert Series
Preheater
Conditions paper for consistent, strong bonding.
What is a corrugated board line?
Preheating rollers wrap the paper web to bring it to an even temperature before the single/double facer, so glue cures consistently across the width. The MH-1100T offers selectable roller diameters and a 360° electrically-adjustable wrap angle to tune the heated area.
Preheat rollers are available at φ600, φ900, φ1000 and φ1100 mm for 1400–2500 mm widths. The electric wrap-angle adjusts 360° (optional twin angle-shafts increase the heated area); roller surfaces are precision-ground and hard-chromed for clean, durable, even heating, with a disc seal-head design. Single or multi-layer configurations.
Key benefits
- Even paper heating for consistent glue cure
- 360° electric wrap-angle adjustment
- Roller diameters φ600 / 900 / 1000 / 1100 mm
- Precision-ground, hard-chromed roller surfaces
- Disc seal-head for uniform heating
- Single or multi-layer configurations
Usage & characteristics
- 01Preheating roller diameter selectable: φ600 / 900 / 1000 / 1100 mm.
- 02Effective width 1400–2500 mm.
- 03Electric wrap-angle adjustment over 360°; optional twin angle-shafts increase the heated area.
- 04Each roller surface is precision-ground and hard-chromed — clean and durable.
- 05Disc seal-head design ensures the base paper is evenly heated.
- 06Single or multi-layer configurations.
Applications & industries
Specifications
- Model
- MH-1100T
- Roller diameter
- φ600 / 900 / 1000 / 1100 mm
- Effective width
- 1400–2500 mm
- Wrap angle
- 360° electric adjust
- Roller surface
- Precision-ground, hard-chromed
Models
- Preheater — MH-1100TMulti-diameter preheater with electric wrap-angle control.
Models
Models & specifications — CorrXpert Series
Each tab is a distinct model type. Where a type comes in several sizes, they are compared side by side.
Preheater — MH-1100T
Multi-diameter preheater with electric wrap-angle control.
Key difference
Tune the heated area on the fly — 360° electric wrap-angle adjustment and selectable roller diameters condition paper evenly so glue bonds consistently and board lies flat.
| Specification | |
|---|---|
| Roller diameter | φ600 / 900 / 1000 / 1100 mm |
| Effective width | 1400–2500 mm |
| Wrap angle | 360° electric |
| Surface | Precision-ground, hard-chromed |
| Configuration | Single / multi-layer |
Preheater — MH-1100T
Request a tailored quotation, full technical drawing and ROI. Installation, operator training and AMC included.
See it in action
Preheater — in operation
Gallery
Return on investment
The numbers that matter
FAQ
Common questions
What does a preheater do?
It warms the paper before gluing so adhesive bonds evenly across the width, improving board strength and reducing warp.
